4.3inch tft lcd with 800X480dots
4.3inch tft lcd with 800*480dots
Product size: 4.3-inch IPS tft LCD 800 * 480
Resolution: 800*(RGB)*480
Overall dimension of module: 67.20 (W) * 105.50 (H) * 2.9 (T) mm
Display area AA size: 53.86 (W) * 95.04 (H) mm
Working temperature: – 30 ℃ – + 85 ℃ wide temperature industrial control panel
Storage temperature: – 30 ℃ – + 85 ℃
Display mode: full color IPS full view
Backlight mode: LED
Touch (TP): capacitive touch \ resistive touch screen
Interface type: RGB / MCU
