2.2inch readable tft lcd module with RGB interface

2.2inch readable tft lcd module with RGB interface

Product size: 2.2-inch TFT LCD (semi transparent and semi reflective)
Resolution: 240 (RGB)* 320dots
Outline size: 56.66 (W) * 40.60 (H) * 2.85 (T) mm
Active area: 45.12 (W) * 33.84 (H) mm
Operating temperature: – 20 ℃ – + 70 ℃
Storage temperature: – 30 ℃ – + 80 ℃
Display mode: full color, half transparent and half reflective
Connection mode: Welding plug connector
Backlight mode: LED
Touch (TP): resistive touch screen / capacitive touch screen
Interface mode: RGB \ MCU \ SPI

2.2inch readable tft lcd module with RGB interface
